Automatic control for solid fuel boilers KG Elektronik SP-18Z

The KG Elektronik SP-18Z automatic control system for solid fuel boilers can simplify room temperature control. This Polish-made controller is suitable for regulating heating system components (heat exchanger, pumps, fan) with a power output of up to 30 kW. This allows for more efficient use of solid fuel, creating a comfortable indoor environment.

Features of the device

The KG Elektronik SP-18Z automation system for solid fuel boilers allows you to set a specific room temperature and maintain it throughout operation. The device monitors both internal and external parameters. Signals from built-in sensors control fan power and the amount of fuel supplied.

When the temperature drops, the boiler does not cool down. Fan blades
Keywords: Automatic control for solid fuel boilers KG Elektronik SP-18Z, Heating, Components for heating equipment, Automatic control for heating equipment, Components for heating equipment
Condition: New
Mains voltage: 220~240 V
Purpose of the component: For solid fuel boilers
Component type: Automatic
Possibility of connecting a room thermostat-program: Yes
Power consumption (W): 2.5
DHW pump control: Yes
Automatic control for: Boiler with feeder (auger)
Fan control: Yes
Underfloor heating pump control: No
Fuel feed mechanism (auger) control: Yes
Solar Collector Pump Control: No
Three-way valve control: No
Throttle Control: No
Second fan control: No
Recirculation pump control: No
Pellet burner control: No
Heating pump control: Yes
Flue gas temperature sensor: No
Lambda probe: No
The range of setting the set temperature, °C: 25...85
Maximum temperature measurement range, up to °C: +99
Heating pump load, up to (A): 0.5
Anti-stop function: Yes
Anti-freeze function: Yes
Warranty period (months): 12
Fan load, up to (A): 1
Fuel level display function: No
Safety sensor (thermal): Yes
Load on the DHW pump, up to (A): 0.5
Depth (mm): 145
Load on the fuel supply mechanism (auger), up to (A): 1.8
