Siemens LME 11.330 C2BT

Gas burner controls LME11.330 for monitoring 1-stage gas burners of low and medium power with intermittent operation mode.

The LME 11.330 C2 burner controls (previously the A2 modification) are used to start and monitor single-stage gas burners with intermittent operation. Flame monitoring is performed using an ionization electrode or a QRA… flame sensor with an AGQ3… auxiliary unit, or using QRC… blue flame sensors.
The overall dimensions of the LME… housing are the same as those of the LGB… and LMG… combustion controllers (see “Overview of modifications”).
– Burner controls comply with EN 298
– Gas burners with fan comply with EN 676
– Low voltage detection
– Monitoring of air pressure by means of functional testing of the air pressure switch during start-up and operation
– Possibility of remote electric reset
- Multicolored indic
Keywords: Siemens LME 11.330 C2, Siemens combustion managers, ignition/combustion controllers, Siemens LME, LME 11.330 C2, landis & gyr, LME11.330C2, burner control, Siemens LME 11 330 C2, LME 11.330.C2
Country of origin: Germany
Condition: New
Purpose of the component: For burners, For gas boilers, For combination boilers, For boiler furnaces
Nominal voltage: 220 V
