Pump group 1 1/4" with mixer NG - 52

Pump group 1 1/4" with mixer NG - 52

The NG-52 pump group with mixer is a prefabricated unit that allows for the elegant, compact, and quick installation of boiler systems with one or more boilers. Pump groups are used in a mixing circuit, where a specific temperature profile must be maintained by mixing cooled return line coolant into the supply line.

They are most often used as a "warm floor" or "radiator heating" circuit with precise temperature control. To implement automatic mixing, you need to select a suitable electric drive and connect it to the control system.

Advantages of pump groups with mixer NG - 52

• During the installation process, the boiler rooms are properly and compactly piping is ensured. In the pump group housing
  Keywords: Pump group 1 1/4" with mixer NG - 52, Termojet quick installation groups, Termojet pump groups, Quick installation groups, Pump groups, pump groups, Pump groups, Heating equipment
  Brand: Termojet
  Connection diameter: 1 1/4"
  Presence of thermal insulation: No
  Power at ∆T=20°C: 85 kW
  Power at ∆T=10°C: 45 kW
  Kvs: 18.1 m3/hour
  Passage speed: ≤ 1 m/sec
  Maximum flow rate: 2.2 m3/year
