Buran 40 kW long-burning boiler

Buran 40 kW long-burning boiler

The Buran 40 kW boiler has a heated area of up to 400 sq. m., weighs 388 kg, and has an efficiency of 87%, with a maximum coolant flow of 0.87 cubic meters per hour. The chimney diameter is 180 mm, the diameter of the heating circuit connection pipes is 1 1/2 inches, and the firebox volume is 0.240 cubic meters. The volume of coolant in the boiler is 68 liters. The chimney height is at least 4.5 m. Overall dimensions are 2100 mm in height and 800 mm in diameter. Made in Ukraine (Certified).

In today's climate, the use of local fuels and the reduction of harmful emissions are increasingly important. In Ukraine, the most accessible and environmentally friendly local fuels are coal, firewood, and wood waste.
The problem of individual heat supply for remote sites without gas supply and with an unstable electricity supply remains relevant to this day.

The BURAN P-10.12.20.40 solid fuel steel boiler is a highly efficient wood-fired boiler that requires no electricity. Designed for heating individual homes and small buildings, the BURAN P-10.12.20.40 boiler will provide warmth and maximum comfort in heated spaces under any conditions.

Advantages of the BURAN P boiler:

• Using a renewable, cheap energy source, namely wood fuel.
• High efficiency due to efficient fuel combustion.
• Autonomous operation - does not require a power source.
• Ecologically safe for the environment.
• The accumulated ash does not interfere with the combustion process of the fuel; it is sufficient to remove it 3-4 times a month.
• The water temperature in the boiler is regulated by an automatic air supply draft regulator.
• Maintaining the temperature set by the consumer by automatically regulating the combustion intensity.
• The burning time of one load of firewood is 12-24 hours.
• No unpleasant odors due to the gas-tight design of the combustion chamber.
• Absolutely silent operation and comfort
• Convenience and safety

• The combustion process is controlled by a simple and convenient regulator, directly linked to the combustion air damper. The desired heating water temperature is set on the regulator, and the boiler automatically maintains it. The actual temperature and pressure are displayed on a nearby pressure gauge.
  The boiler's heat exchanger is designed as a water jacket running the entire length of the boiler, ensuring rapid heating and high efficiency. Fireproof doors ensure a high level of fire safety, and the insulated casing protects against burns upon contact.
  For safe operation, it is necessary to install a safety relief valve or safety group in the heating system.
  Versatility

  The BURAN P solid fuel steel boiler is available in four power ratings: 10, 12, 20, and 40 kW, providing the heating needs of virtually any private home or other small space. For heating larger areas, multiple boilers can be cascaded.

  The boiler operates with both closed and open heating systems.

High efficiency and cost effectiveness

Air from the atmosphere enters the air preheating chamber and is then directed through an extendable air duct. Directly delivering preheated air to the combustion zone ensures the most efficient combustion of the fuel, minimizing soot and smoke formation. The fuel evenly distributes air throughout the combustion zone. The optimized combustion process ensures a standard efficiency of up to 86%.
The "top-down combustion" principle prevents the entire fuel load from burning out at once—it burns gradually as air is supplied. A single load of wood, depending on the density and specific operating conditions, is sufficient for 12-24 hours of boiler operation in maintenance mode or with a selected boiler with sufficient power. The boiler's burner is made of special heat-resistant steel, ensuring long-lasting operation.
The height of the insulated chimney must be at least 4.5 m. The end of the chimney must be at least 0.5 m above the building's ridge. Detailed recommendations for the use and configuration of solid fuel boilers are described in the operating manual.
.
