Altek ASP-315P-72 Polycrystalline Solar Panel
Altek (Alternative Technologies) is one of the Ukrainian market leaders in renewable energy. This manufacturer takes a responsible approach to its work and participates in various exhibitions and conferences on alternative energy.

Since the end of 2017, Altek has been producing solar panels at the facility of one of the world's leading brands, Risen Energy. As a top-10 global Tier 1 brand, its product quality requirements are significantly higher. Consequently, the Altek solar panel labeling was changed (since 2018) from ALM to ASP for high-power PV modules.

Purpose:

The Altek ASP-315P-72 polycrystalline solar module is a device that converts solar energy into
Keywords: Polycrystalline photomodule ASP-315P-72, Solar photomodules (batteries), Solar photomodules and components, Alternative energy sources, Polycrystalline photomodule ASP-315P-72, solar
Country of origin: China
Weight: 17.6 kg
Voltage: 30.63 V
Power: 260
Weight, kg: 17.6
Dimensions, mm: 1640x992x40
Open circuit voltage: 37.97 V
Panel type: Polycrystalline
Short circuit current: 9.05 A
Frame: Anodized aluminum alloy
Element Type: Polycrystalline
Operating temperature, °C: from -40° to +85°C
Permissible power deviation,%: ±3
Short-circuit current, A: 9.05
Front glass: Low iron tempered glass
Maximum power, W: 260
Current at maximum power, A: 8.49
Maximum network voltage, V: 1000
Open circuit voltage, V: 37.97
Sealant: EVA
Voltage at maximum power, V: 30.63
Number of elements: 60 6x12
Module efficiency,%: 15.99
