Automation for solid fuel boilers Tech ST-28 Sigma

Tech ST-28 Sigma solid fuel boilers are the simplest and most economical heating system. They operate on fuels such as wood, coal, and other fuels, and offer several advantages:

• autonomy;
• simplicity;
• low cost;
• Possibility of installation in places where there is no access to gas supply.

The Tech ST-28 Sigma automation system is mounted directly to the boiler body. Made of high-quality, heat-resistant material, it is resistant to high temperatures.

Solid fuel boilers also have a number of disadvantages:

• the need for regular fuel loading;
• volumetric dimensions;
• continuous monitoring of equipment operation;
• the need to clean the boiler.

With many shortcomings
Keywords: Tech ST-28 Sigma automation for solid fuel boilers, Heating, Heating equipment components, Heating equipment automation, Heating equipment components
Condition: New
Mains voltage: 220~240 V
Purpose of the component: For solid fuel boilers
Component type: Automatic
Possibility of connecting a room thermostat-program: Yes
Power consumption (W): 4
DHW pump control: Yes
Automatic control for: Manually loaded boilers
Fan control: Yes
Underfloor heating pump control: No
Fuel feed mechanism control (auger): No
Solar Collector Pump Control: No
Three-way valve control: No
Throttle Control: No
Second fan control: No
Recirculation pump control: No
Pellet burner control: No
Heating pump control: Yes
Flue gas temperature sensor: No
Lambda probe: No
Temperature setting range, °C: +45...+80
Heating pump or DHW pump control: No
Maximum temperature measurement range, up to °C: 85
Heating pump load, up to (A): 0.5
Fan load, up to (A): 0.6
Fuel level display function: No
Safety sensor (thermal): Yes
Load on the DHW pump, up to (A): 0.5
