Automation for solid fuel boilers Prond Proton 440 CWU PID

The Prond Proton 440 CWU PID automation system is a temperature controller designed specifically for solid fuel boilers with manual loading. It balances the operation of the circulation pump and fan, preventing malfunctions in the heating system. The benefits of installing the controller will be noticeable after just one month of operation. The control unit minimizes user intervention and fuel consumption. The enhanced temperature control system and PID function are its key advantages.

Features of operation

The Prond Proton 440 CWU PID automation stabilizes fan rotation, ensuring optimal speed. The controller prevents the system from exceeding the set limits, preventing premature wear. Extended service life
Keywords: Automation for solid fuel boilers Prond Proton 440 CWU PID, Heating, Accessories for heating equipment, Automation for heating equipment, accessories for heating equipment
Condition: New
Mains voltage: 220~240 V
Purpose of the component: For solid fuel boilers
Component type: Automatic
Possibility of connecting a room thermostat-program: Yes
Power consumption (W): 2
DHW pump control: Yes
Automatic control for: Manually loaded boilers
Fan control: Yes
Underfloor heating pump control: No
Fuel feed mechanism control (auger): No
Solar Collector Pump Control: No
Three-way valve control: No
Throttle Control: No
Second fan control: No
Recirculation pump control: No
Pellet burner control: No
Heating pump control: Yes
Flue gas temperature sensor: No
Lambda probe: No
Set temperature setting range, °C: 35...90
Heating pump or DHW pump control: No
Maximum temperature measurement range, up to °C: 100
Heating pump load, up to (A): 0.5
Anti-stop function: Yes
Anti-freeze function: Yes
Fan load, up to (A): 0.5
Fuel level display function: Yes
Safety sensor (thermal): Yes
Load on the DHW pump, up to (A): 0.5
