ATON Compact 16E

ATON Compact 16E (Aton AOGVMND-16E) - parapet, single-circuit gas heating boiler, heated area - 160 m2, power - 16 kW, gas consumption - 1.8 m3 / hour, automation "EUROSIT", dimensions (HxWxD) - 700x740x275 mm.

The AOGVMND-16E is a parapet, single-circuit gas heating boiler from ATON (AOGVMND-16E) . The boilers utilize safety and control automation from EUROSIT - Sit Group (Italy).

Main characteristics:

• Nominal thermal power, kW: 16±0.5
• Heat exchanger material: Steel
• Efficiency, not less than, %: 90
• Fuel: Natural gas according to GOST 5542
• Nominal gas pressure, Pa: 1274±100
• Volume of water in the boiler, not less than, l: 25
• Temperature of combustion products at the boiler outlet, not less than, °C: 110
• Boiler air consumption volume, m³/h: 18±1.8
• Thickness of the external wall of the room,
